Kbic-120 dc motor speed control 9429A # 5603G


The KBIC-120 is a 115 VAC rated 9 Amps RMS @ 45C. The control is designed for 90 VDC PM, Shunt and AC/DC motors. It will control motors between 1/100-1/2 HP (1.0 HP w/aux. Heat sink) by inserting the proper Plug-in Horsepower Resistor®. Speed range is 50:1 with load regulation of 1%. Features include Auto Inhibit®, Voltage Following, MOV transient protection, 5K speed pot and trimpot adjustments for Min, Max, Accel, IR and CL. Options include Auxiliary heat sink, AC Line and Armature Fuse Kit, Barrier Terminal Board, RFI/EMI filters and Signal Isolation (model SI-5).
Although this item came out of a working facility, we have no way of testing it.
If you have any questions please feel free to contact us.
Be sure to add me to your favorites list!
We guarantee that the item pictured will be the exact same you will receive and will perform in the manner stated in the description. If you are not clear on the description please send us an email and we will clarify.
Our email address is i-****@charter.net
Our phone number is (***)-627-3135
THE BEST WAY TO GET A QUESTION ANSWERED IS VIA EMAIL! WE CHECK OUR EMAIL MONDAY – FRIDAY 9-5PM!
