Test lead wire - 50FT high quality soft and flexible
50' of quality tinned conductor 18 gauge test lead wire, 25' each of red + black. The fine stranded conductor and soft rubber insulation combine to make this wire super flexible and makes it much less tangle prone than cheaper wire with plastic insulation.
* Conductor: Fully-annealed, stranded tinned copper per ASTM B-33 ·
* Insulation: Premium grade color coded rubber ·
* Temperature range: -20̊C to +60̊C Rubber ·
* Conductor Size (AWG): 18 ·
* Conductor/Strands: 65/36 ·
* Nominal Insulation Thickness 0.045 ·(in):
* Nominal Insulation Thickness 1.14 ·(mm):
* Breakdown Voltage (AC, ms): 20,000V ·
* Nominal Outside Diameter (in): 0.140 ·
* Nominal Outside Diameter 3.56 ·(mm)
If image hosting service is down and photo does not show up, please ask for an e-mailed copy.
