Altronixs ALTV248175ULCB power supply 8 fused outputs


UL/CUL Listed CCTV AC Wall Mount 8 Output Power Supply
• UL Listed UL Listed for Commercial CCTV Equipment (UL2044),
CUL Listed - CSA Standard C22.2 No.1-98, Audio, Video
• 24VAC or 28VAC selectable output.
• 7 amp @ 24VAC or 6.25 amp @ 28VAC (175VA) supply current.
• Eight (8) PTC protected outputs.
• Output PTCs are rated @ 2.5 amps.
• 115VAC 50/60Hz, 1.73 amp input.
• Illuminated Power Disconnect Circuit Breaker with manual reset.
• Unit maintains camera synchronization.
• Lifetime Warranty. With manufacturer
* Enclosure Dimensions: 12.25”H x 7.25”W x 4.5”D
* 1/2" and 3/4" combination knockouts
GREAT FOR CLOSED CURCUIT CAMERAS, ACCSSESS CONTROL, SECURITY SYSTEMS
FOR MORE INFORMATION CONTACT MANUFACTURER FOR DRAWINGS AND SKEMATICS POWER SUPPLY CALCULATIONS
