Riland 2 pin male & female panel chassis connector kit
Picture shows 3 kits, you get 1.
Riland 2 pin Male & Female Connector Kit
You get the kit shown (not all 3, only 1 set). These are brand new and used for welding machine connections, electrode holders, extensions for welding cables, etc... Riland and other welding machines use these connectors for spoolguns, mig connections, cables, power plugs, etc...
These connectors easily handle heavy current. They are used on many of the Riland brand machine connections. They are continuous thread twist secure lock. These are made of chrome plated brass.
The Chassis mounted male side is 2pin, all tinned copper posts and is 9/16" Diameter for mounting, comes with mounting hardware.
The cable mounted female side is also 2pin, all tinned copper sleeves and will only mount the Chassis connector one way - via tongue and groove.
Rated: 5amps at 110vac or 12vdc at 20amps (1200v max per pin)
Dimensions: Complete <2" Long. Chassis is 7/8" Long, Cable is 1-3/8" Long.
Wire: will accept 0.079" or 2mm Diameter stranded or solid wire= close to 14AWG Gauge.
Each win gets 1 kit which consists of chassis mount and cable connector.
We have lots of other connectors in our listings, including dinse 25, 50, 2pin, 3pin, 5pin, 7pin and female dinse connectors.
