Madison electric arf-t-25 ac tachometer speed sensor
Madison Electric ARF-T-25 is a flange mount 3 inch diameter unit with 5/16 inch flattened stainless steel shaft and 6-32 output terminals. Output frequency is seven sinewave cycles per revolution and quite accurate. Self-genreating output voltage is 33.40 volts at 1000 RPM and 60 volts at 1800 RPM to 1% unloaded accuracy.
Speed range is 50-8000 RPM. Precision ball bearing design. Alnico VI permanant magnets. Self-powering. Molded plastic case. 4 in-oz starting torque, 2 oz-in running torque.
You can click here to reach the Madison Electric (now Thermotion) web site.
You can click here to reach the ARF-T-25 data sheet.
