Ditak 8 - adjustable timebase 5-digit rate indicator
DITAK 8 - ADJUSTABLE TIMEBASE 5-DIGIT RATE INDICATOR
LCD, POSITIVE REFLECTIVE OR NEGATIVE TRANSMISSIVE WITH YELLOW/GREEN OR RED BACKLIGHTING
0.6 INCH (15.2 mm) HIGH DIGITS
ADJUSTABLE TIMEBASE FROM 4 MSEC TO 32 SEC
INTERNAL LITHIUM BATTERY PROVIDES OVER 7 YEARS OF CONTINUOUS OPERATION
NEMA 4X/IP65 SEALED FRONT PANEL BEZEL
ACCEPTS MAGNETIC OR LOGIC TYPE SIGNAL INPUTS
WIRE CONNECTIONS MADE VIA SCREW CLAMP TYPE TERMINALS
The Ditak 8 is a self-powered rate indicator which features selectable Timebase Increments by setting the appropriate DIP switches on the rear of the unit. The internal 3.0 VDC lithium battery will operate continuously for at least 7 years. It has a 5-digit LCD display with 0.6 inch (15.2 mm) high digits. The displays are available in positive image reflective (black digits, reflective background) or negative image transmissive (illuminated digits, dark background) with red or yellow/green backlighting. Backlight version units require power from an external 9 to 28 VDC supply. The unit is constructed of a lightweight, high impact plastic case with a clear viewing window. The sealed front panel meets NEMA X/IP65 specifications for wash-down and/or dusty environments, when properly installed. The optional Micro Line/Sensor Power Supply (MLPS1000) is designed to attach to the rear of an installed Ditak 8. The optional supply can be powered from 85 to 250 VAC, and can provide power for the backlighting of a unit and most sensors.
DISPLAY: 5-Digit LCD, 0.6" (15.2 mm) high digits.
POWER SOURCE: Internal 3.0 V lithium battery provides over 7 years of continuous service (battery life is dependent upon usage).
BACKLIGHT POWER REQUIREMENTS: 9 to 28 VDC @ 35 mA. Above 26 VDC, derate operating temperature to 50°C. Must use the MLPS1 or a Class 2 or SELV rated power supply.
SIGNAL INPUT: 0 to 10 KHz from a magnetic or bi-polar output (with a 50% duty cycle). Min. input sensitivity is 0.9 V. Max. input = 28 VDC.
TIMEBASE: Adjustable in 1/256 sec (3.906 msec) increments via DIP switches located at the rear of the unit. Timebase ranges from 3.906 msec to 31.998 sec; 0.01% ±1 digit accuracy.
: 0 to 60°C (Above 50°C derate backlight operating voltage to 26 VDC max.)
Operating and Storage Humidity
: 85% max. (non-condensing) from 0°C to 60°C.
CONSTRUCTION: High impact plastic case with clear viewing window (Panel gasket and mounting clip included). Installation Category I, Pollution Degree 2.
