Astrosystems A1205R synchro/resolver bridge (defective)
Astrosystems A1205R Synchro/Resolver Bridge (Defective)
Astrosystems A1205R Synchro/Resolver Bridge (Defective/Parts Unit)
The A1205R Decade Synchro/Resolver Bridge is designed to permit the testing of precision Synchro or Resolver signals to a high degree of absolute accuracy.
* Maximum input voltage (rms) is 0.35 x frequency (in Hz), not to exceed 170 V rms
* For rated accuracy, input frequency range is 400 Hz to 800 Hz
* 359.999° equivalent rotor range
* 1 MW/400 Hz input impedances in Synchro mode
* 750 kW/400 Hz input impedances in Resolver mode
* Output error voltage gradient is 4.85 µV/S/V input
SKU: AA094NRC00SN: 5191Loc: BH03AD
