National LMX2322 2GHZ pll rf synthesizer 100PC lots h@t
NATIONAL SEMICONDUCTOR CORP2GHz (2.5GHz) PLL SYNTHESIZER IC
PACKAGE: 16-PIN CHIP SCALE PKG NATIONAL LDO PN: LP2981AIM5X-3.8
WORKS TO ABOUT 2.5GHz WITHOUT ANY PROBLEMS
OPERATES ON 2.7-3.9VDC BUT CAN WORK ON 5VDC 100PCS LMX2322 & 100PCS LP2981-3.8 ARE INCLUDED
SELLING 10EA 100PC BUNDLES CHEAP!
Image Hosted by VDB Engineering Inc. http:// .com
UP FOR SALE ARE 1-10 100PC LOTS OF A NATIONAL 2GHz (2.5GHz) SMT PLL RF SYNTHESIZER WITH INTERNAL DIVIDE BY 32/33
PRESCALER. THIS SYNTHESIZER WAS DEVELOPED FOR CELLPHONE USE THUS IT'S NOW BEING USED BY SOME IN RF JAMMER
CIRCUITS FOR CELLPHONES, WLAN, WIRELESS VIDEO & OTHER STUFF OF WHICH WE ARE NOT INVOLVED NOR DO I WISH TO
USES FOR THIS PART. SMALL PLL CONTROLLED MATCHBOX FM WIRELESS TRANSMITTER, 900, 1200, & 2400MHz VIDEO GEAR
BOTH FOR TRANSMITTER & RECEIVER SIDES, GPS RECEIVER, & LOTS OF OTHER COOL STUFF, & ALL FOR CHEAP FROM US!
ALSO INCLUDED AS AN ADD-ON ARE 1-10 LOTS OF A NATIONAL SOT-23 5 PIN PKG 3.8VDC 100Ma LOW DROPOUT REGULATOR
WHICH WILL SUPPLY MORE THEN ENOUGH CURRENT TO RUN THIS UNIT WITH MINIMAL HEAT WHEN IN NORMAL OPERATION.
EACH PURCHASE OF A 100PC LOT OF THE LMX2322 PLL SYNTHESIZER CHIP DOES ALSO INCLUDE AS PART OF THIS BUNDLE
100PCS OF THE NATIONAL 3.8VDC 100Ma LDO REGULATOR. SO YOU ARE REALLY GETTING 200 PARTS AS 100PCS OF EACH!
THESE PARTS ARE EASY TO CONTROL USING A MPU. PLEASE USE THE PROVIDED LINK BELOW FOR THE MNF'S DATASHEET TO
HELP ANSWER ANY & ALL OF YOUR QUESTIONS. THESE ARE SOME OF THE COOLEST STUFF OUT AS FAR AS SYNTHESIZER IC'S
GO, AND THEY ARE NOT SECONDS OR REJECTS... JUST PRIME PARTS THAT ARE CELLPHONE MNF'S SURPLUS STILL ON REELS PARTS WILL COME ON THE TAPE AS REMOVED FROM THE MNF'S REEL. LOTS ARE A MINIMUM OF 100PCS WITH SOME EXTRA'S
ADDED FOR GOOD MEASURE. THEN IT WILL BE PACKED IN A BUBBLE WRAP PADDED ENVELOPE & MAILED OFF TO YOU IN ANY
COUNTRY IN THE WORLD. (PLEASE NOTE THAT SOME COUNTRIES DUE TO CERTAIN LAWS ARE NOT INCLUDED!) THERE IS NO NEED TO FEAR THIS TYPE OF PACKAGE, WHY BECAUSE IT IS NOT ALL THAT HARD TO WORK WITH AS LONG AS
YOU CAN HANDLE SOLDERING TO 0603 SIZE SMT PARTS. HOW YOU ASK? SIMPLE, IT IS CALLED DEAD BUG STYLE! AND IT IS
JUST TURNING THE PART ON ITS BACK WITH IT'S PADS UPWARD. JUST LIKE A DEAD BUG ON IT'S BACK. A SPOT OF GLUE TO
HOLD IT IN PLACE & ALL YOU DO IS SOLDER A SHORT PIECE OF WIRE WRAP WIRE TO EACH PAD THEN TO THE PCB UNTIL IT
IS ALL WIRED IN. THUS THE SO CALLED CHIP SCALE PART NOW ENDS UP AT YOUR MERCY & AT A CHEAP PRICE TO BOOT! WE ALSO SELL A 3.6V 50Ma & 3.8V 100Ma LDO REGULATOR THAT WILL POWER THIS PLL CHIP IN OUR STORE FOR A GREAT
PRICE ALSO SO YOU ARE ALL SET PLUS THIS PLL CHIP CAN USE JUST ABOUT ANY REFERANCE OSCILLATOR FREQUENCY!A SEARCH IN GOOGLE USING 'LMX2322' WILL PROVIDE YOU WITH A LOT OF SELLERS OF THIS PART BUT THERE IS ALSO
A WEBSITE THAT USES THIS PART IN A FEW OF ITS FREE TO BUILD DESIGNS LIKE A 2.5GHz FREQ COUNTER PLUS A NICE
2.5GHz DIVIDE BY 1,000 OR 10,000 PRESCALER. AND THERE IS A LOT MORE. SITE IS IN SWEDAN BUT IS WRITTEN IN GOOD
THANKS FOR LOOKING & GOD BLESS!
