Nice anorad servo controller drive model d-serv-DLM2-5
NICE ANORAD SERVO CONTROLLER DRIVE MODEL D-SERV-DLM2-5
This is a very nice drive in excellent condition and it is fully guaranteed.
* Position range: ± 999,999,999 counts
* Velocity range: ± 1 to 10,000,000 counts/sec
* Acceleration range: 1,000 to 127,000,000 counts/sec2
* Servo Update Rate: 20 kHz Encoder input: 3 channel differential line receiver
* Communication: RS232,RS422,programmable to 9,600 baud
* Analog Inputs: ± 10V, 12 bit resolution, 2/axis (M-SERV) ± 10V, 12 bit resolution, 1/axis
* Analog Outputs: (1) ± 10V, with 10 bit resolution/axis, (1) General purpose Dedicated
* Inputs:(2) limits, emergency stop, opto-isolated. (48) inputs
* Digital Inputs:(8) single axis, (16) multi axis, opto-isolated. (48) inputs
* Digital Outputs:(8) single, (16) multi axis, opto-isolated, supported by a built-in 24V opto-isolated supply, (0.5A)
Any questions? Email us at ****@dockhardware.com or call 1-(***)-826-3433 9 to 5 EST.
