New instek gsp-827 spectrum analyzer 2.7 ghz
Instek GSP-810 Spectrum Analyzer
Internet Security By ControlScan Internet Security By ControlScan Internet Security By ControlScan Internet Security By ControlScan
Instek GSP-827 Spectrum Analyzer
* Frequency Range: 9 kHz to 2.7 GHz
* Synthesized-based design provides accurate and high RF performance.
* Tracking generator provides frequency response measurement.
* ACPR, OCBW, CH Power offer the measurement in communication system.
* Variety of external reference clock (64k~19.2M) to adapt to different applications.
* Provides Quasi-Peak and optional filters for EMI test.
* 10 Markers with complete functions: Delta mode, Peak functions, Marker Track.
* Trace functions: Two trace with Peak Hold, Freeze, Average, Trace Math.
* Detect Modes:Normal, Sample, Peak, Quasi-Peak
* Limit line: Upper and Lower limit with Pass/Fail test
* Trigger functions: Video, External
* Spilt Windows: Dual display windows
* Clock/calendar: Provides time/date in saved data.
* Input Impedance: 50 Ohm physical, changeable by set and offset calibrated
* Reference clock output: 10MHz
* Wide range of external reference clock: 64k, 1M, 1.544M, 2.048M, 5M, 10M, 10.24M, 13M, 15.36M, 15.4M, 19.2M
* Light-weight of 4.5 kg design
* 100 trace files with date/time won’t lose any measurement.
* AC/DC/Battery multiple power mode operation provides more flexibility.
* GPIB and RS232 interface with PC for ATE system.
* 1 - ATN-100 10dB attenuator
* 2 - ADP-002 N-SMA adapters
* 2 - GTL-303 RF cables (SMA-SMA, RD316, 600mm)
* 2 - ADP-001 N-BNC adapters
* 2 - ADP-101 50? to 75? adapters
* 2 - GTL-304 RF cables (N(p)-N(J), RG223, 300mm)
* 1 - GAK-002: Cap with Chain
* 2 - GTL-302: RF cable (N(P), RG223, 300mm)
Spectrum Analyzer - 150KHz-2.7 GHz
Spectrum Analyzer - 9KHz-3 GHz
GSP-810 & 827 RF cable N type male connect
Tracking Generator, factory installed
Battery Pack, factory installed
+/- 1ppm stability, factory installed
GPIB interface, factory installed
DC Car Cord - Only works with Battery Pack (GSP-827-Opt02)
EMI Filters, factory installed
Demodulator, factory installed
EMI filters and 300Hz RBW, factory installed
EMI filters and Demodulator, factory installed
EMI filters, 300Hz RBW, Demodulator, factory installed
Click here to download the Instek GSP-827 manual (PDF)
Click here to download the Instek GSP-827 specs (PDF)
2kHz to 2.5GHz in 1/2/5sequence, full span, zero span
-85dBc/Hz @1GHz 20kHz Offset typical
-105dBm to +20dBm 10M to 2.5GHz
-100dBm to +20dBm 2.5GHzm to 2.7GHz
-30 to +20dBm, overload protected
<-40dBc, RF Input
<-60dB, Down from Reference Level
External reference clock inputFrequency
64k, 1M, 1.544M, 2.048M, 5M, 10M, 10.24M, 13M, 15.36M, 15.4M, 19.2M
640 x 480 high resolution graphical LCD, B&W
Trace memory and math, Marker search functions,
CE, Installation category II, pollution degree 2
AC/DC/Battery Operaion with Battery Pack
IAC 100~240V; DC 12V; 10.8V Li-Ion Battery Pack
RF cable(SMA-SMA, RD316, 600mm) x2
RF cable(N(p)-N(J), RG223, 300mm) x2
RF cable(N(P), RG223, 300mm) x2
GTL-401: DC Power cord with DC jack and lighter plug, current 5A
RBW Selections: 9kHz and 120kHz, 6dB bandwidth
Output: Internal speaker, 3.5mm stereo jack wired for mono operation
RBW Selections: 9kHz and 120kHz, 6dB bandwidth 300Hz, 3dB bandwidth
EMI Filters and Demodulator (*)
RBW Selections: 9kHz and 120kHz, 6dB bandwidth
Output: Internal speaker, 3.5mm stereo jack wired for mono operation
EMI Filters, 300Hz RBW, and Demodulator (*)
RBW Selections: 9kHz and 120kHz, 6dB bandwidth 300Hz, 3dB bandwidth
Output: Internal speaker, 3.5mm stereo jack wired for mono operation
NOTE (*): Only one option can be installed for one given GSP-827 unit
