Electroswitch 4 pole 2 pos heavy duty switch 20A 600V
Only TWO remaining of this exact style!
Electroswitch is one of the finest manufacturers of heavy duty electrical utility quality
switches and similar products. These are often hard to find and outrageously priced.
The switches are rated 2 horsepower or 20 amps at 110 vac up to an unusually
high 6 amps at 600 vac. They typically are three inches in diameter and each pole
adds 5/8 of an inch to the switch depth. The shaft is an industrial standard 1/4 inch square.
These are perfect for motor controls, robotics, automation, or other
shop floor uses where a premium quality, super rugged switch is
required for direct control of motors and similar higher current loads.
Offered here is a two deck version with two contact sets
of two positions per deck. As provided, the switch provides
four single pole "make" contacts. Contacts can easily be
rearranged for any mix of 4 pole make or break contacts.
They also can be rearranged to form one DPDT switch
and one separate make or break contact.
The shaft extends only 3/8 inches out the front, so some knob
creativity may be needed. There is an optional keyed knob retaining
bracket that is easily removable. Knob and bezel are not included.
Switch extends 3 inches behind panel. Three point 10-32 mount.
You can click here to reach the Electroswitch Series 24 datasheet.
Image shown is of a typical switch in our offerings. The switch
being listed here has two decks and two independent pairs of four
contact positions per deck. #8 Binder screw terminals.
Guaranteed usable. Received by us as public power company surplus.
Removed from equipment, cleaned, and checked. Condition is typicallly
"near new". May include minor cosmetics. Accessories as noted.
deck industrial heavy duty panel mount switch rated to 600 volts. 4PST NO
$6.85 for the first switch and $2.35 for the second..
AZ residents add 8.1% sales tax.
