New 850B smt smd hot air rework station solder station,
850B SMT SMD HOT AIR REWORK STATION SOLDER STATION, NEW
This is a brand new, Model 850B soldering/rework station from Atten, an entry level desoldering/soldering rework station for surface or hole mount components. With 850B, you get a temperature controlled rework station in a compact and convenient setup. The unit comes with two nozzles (A1130 (4.4mm round) and A1170 (7.2x10mm round)) for surface mount components (see second and third picture for more details). We also carry extra nozzles, please email us for more information or check out other items for sale.
With the hot air output of this unit, you can perform surface mount rework in seconds, without damage to either components or PC boards. Just attache a nozzle onto the hot air tool, place the nozzle over the QFP, SOP, PLCC or SOJ to be desoldered, apply hot air to melt the solder without ever touching the component or PC board, and gently lift the component from the board. Soldering of the replacement SMD is just as easy. Other applications include thermal testing of electronic components, shrink-wrapping protective packaging, and welding thermoplastics. Station is made of metal and coated with a static-dissipative paint, so itÂ’s totally ESD-safe.
Compact and versatile, with built in air pump, so there is no need for external compressed air source.
* Separate control for temperature and air pressure for most demanding work
* Hot air temperature: 100C to 480C
* Power consumption: 300W(Max).
* Nozzles are exchangable with Hakko and other hot air soldering stations.
* Power: 110 V AC/ 300W(Max).
* Additional nozzles availabe for purchase.
