Lorain RL100D50 rectifier emerson
The condition appears new and unused, this item is sold as an out of box product. There are a few scratches on it as well, but nothing to hinder its functionality.
Float Voltage Range - 48.0 VDC TO: 58.0 VDC
Equalize Voltage Range - 48.0 VDC TO: 58.0 VDC
Nonselective Factory Adjust High Voltage Shutdown Set Point - 59.46 VDC
Selective High Voltage Shutdown Set Point - 54.92 VDC
Float Voltage Set Point - 52.08 VDC Negative Load Sharing Voltage: Nominal Input, full load - 8.00 VDC
Float Voltage: High Input, no load - 52.18 VDC Nominal Input, no load - 0.02 VDC
Float Voltage: Low Input, full load - 51.95 VDC Current Limit Range - 50 A TO: 120 A
Equalize Voltage Set Point - 54.00 VDC Current Limit Factory Set Point - 110 A
Equalize Voltage: High Input, no load - 54.10 VDC Voice Band Noice - 16.5 dBrn-C
Equalize Voltage: Low Input, full load - 53.87 VDC RMS Noice - 10.0 mV RMS
T2 Transformer: between terminals 1-2 = 16.70 VAC
