Agilent oc-3 amtprobe atm/oc-3 interface J3972A no res
Just pulled from the State, and it was a working unit. Replaced , well because its the state.
I have no means to check it, but as I stated it was working when they decided to "retire" it.
A little info on this, even though I am sure you already know about these.
I am opening with a low price and no reserve on this as I just have too much stuff and need to let go of some of it.
The Agilent J3972A OC-3 ATMProbes are MIPS-based, SNMP-managed ATM interface monitor for OC-3 Asynchronous Transfer Mode (ATM) networks. The ATMProbe is an intelligent device that must be physically located at the site where the ATM circuits reside.
The base hardware configuration supports an OC-3 ATM interface, a 10Base-T/100Base-TX telemetry interface, and a SLIP connection. The OC-3 ATMProbe can also be ordered with an optional Token-Ring telemetry interface. The OC-3 ATM interface supports monitoring both directions of a full-duplex circuit simultaneously. Probe data is retrieved using SNMP via a LAN or SLIP connection.
The 10Base-T/100Base-TX telemetry interface uses a RJ-45 connector. The Ethernet telemetry interface uses an AUI connector. The telemetry port retrieves data associated with the other interfaces on probe, but does not maintain RMON or other network statistics for its own network. The optional Token-Ring telemetry interface uses either an RJ-45 or DB-9 connector. The OC-3 ATM interface uses either multimode or single-mode transceivers with two Fiber SC connectors.
http://cp.literature.agilent.com/litweb/pdf/5988-6026EN.pdf
The link is to Agilent site with the manual in PDF
Keep checking back as I have quite a few things I aquired. I will be listing 2-3 AMP bypass switch modules that go hand in hand with these.
