> New condor power supply m/n: F24-12-a+ - in box
New condor power supply m/n: F24-12-a+ - in box
100, 120 and 240 Vac: +10%, -13%; 215 Vac: +12%, -11
%; 47 to 63Hz. Tolerance for 230 Vac operation is +15%,
-10%. Derate output current 10% for 50 Hz operation.
See voltage rating chart. Adjustment range ±5% minimum
± 0.05% for a 50% load change.
3 mV +0.05% of output voltage, peak to peak maximum.
All “3-terminal regulator” outputs: 3 mV +0.2% peak to
<50 microseconds for 50% load change.
Automatic current limit/foldback.
Built-in on all 5 V models, set at 6.2 V ±0.4 V. Other models
use optional overvoltage protection.
Provided on all models; open sense lead protection built-in
±0.05% for 24 hours after warmup.
0 to 50°C full rated, derated linearly to 40% at 70°C.
5 V units: 45%; 12 and 15 V units: 55%; 20 and 24 V units: 60%.
Logic Inhibit and Current-Share
Per Mil-Std-810D, Method 514.3, Category 1, Procedure 1.
Per Mil-Std-810D, Method 516.3, Procedure III.
FOR MORE INFORMATION PLEASE CLICK THE FOLLOWING LINK:
http://alliedelec.com/Search/ProductDetail.asp?SKU=744-2412&MPN=F24-12-A%2B&R=744%2D2412&sid=47A65580183E617F
For packaging 1-149 pounds click the below brown letters link
For packages OVER 150 pounds or more use click onto the below blue USF HOLLAND link calculator
Enter 49444 in the Origin field
Enter your destination Zip Code in the Destination field
Enter 45% in the Discount % field
Enter the weight of the product in the Weight field
Press the Get rate quote button
